EBR77562705 LG Range PCB Assembly,Main

Restore full control functionality to your LG range with the genuine OEM EBR77562705 Main PCB Assembly. This is the primary control board that manages oven temperature regulation, burner ignition, timer functions, and display output — when it fails, the range may become unresponsive or behave erratically.

Compatible With:

• LG LRE3061ST, LRE3061SW, LRE3061BD (6.3 cu. ft. Electric Range)
• LG LRE3194ST, LRE3194BD (6.3 cu. ft. Electric Range with EasyClean)
• LG LRE3083ST, LRE3083SW (6.3 cu. ft. Electric Range)
• LG LSE4616ST, LSE4616BD (6.3 cu. ft. Slide-In Electric Range)
• Check your model tag (inside the door frame or storage drawer) to confirm fit — PCB revision letters affect compatibility

Key Features & Benefits:

• Genuine OEM Part: LG-manufactured board with the correct firmware, connector layout, and component spec for your model.
• Restores Full Range Control: Resolves unresponsive touch controls, oven not heating, error codes (F1, F3, F7, F9), display failure, or burners not responding to input.
• Direct Plug-In Replacement: Matches original connector positions and mounting holes — no modification required.

Specifications:

• Part Number: EBR77562705
• Part Type: Main PCB Assembly / Control Board
• Compatible Appliance Type: LG Freestanding & Slide-In Electric Range
• Voltage: 120V
• OEM Manufacturer: LG Electronics

Installation Notes: Disconnect power at the breaker before starting. The main PCB is located behind the rear control panel — remove the back cover to access. Photograph all wiring harness connections before disconnecting. PCB revision letters (e.g., 705 suffix) must match your existing board — do not substitute a different revision. Professional installation recommended if unfamiliar with appliance electronics.

Part #: EBR77562705
